9V 5A 12V 4A 15V 3A 24V 2A Wall Mount Power Adapter AU EU US UK KR JP CN Plugs

Shenzhen Ying Yuan Electronics Co., Ltd.
Contact Now
    Buy cheap 9V 5A 12V 4A 15V 3A 24V 2A Wall Mount Power Adapter AU EU US UK KR JP CN Plugs from wholesalers

    Buy cheap 9V 5A 12V 4A 15V 3A 24V 2A Wall Mount Power Adapter AU EU US UK KR JP CN Plugs from wholesalers
    • Buy cheap 9V 5A 12V 4A 15V 3A 24V 2A Wall Mount Power Adapter AU EU US UK KR JP CN Plugs from wholesalers
    • Buy cheap 9V 5A 12V 4A 15V 3A 24V 2A Wall Mount Power Adapter AU EU US UK KR JP CN Plugs from wholesalers

    9V 5A 12V 4A 15V 3A 24V 2A Wall Mount Power Adapter AU EU US UK KR JP CN Plugs

    Ask Lasest Price
    Brand Name : Fullpower
    Model Number : 16190
    Certification : FCC,UL,CE,UKCA,SAA,KC,PSE,CCC,etc
    Payment Terms : T/T, Western Union
    Supply Ability : 100000PCS/Day
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    9V 5A 12V 4A 15V 3A 24V 2A Wall Mount Power Adapter AU EU US UK KR JP CN Plugs

    9V5A 12V4A 15V3A 24V2A Wall-mount Power Adapter AU EU US UK KR JP CN Plugs 2.1*5.5 2.5*5.5 Connector


    Data-sheet

    FEATURESSAFETIES APPROVALSPRODUCTS PICTURE

    v AU US UK EU CN JP KR Plugs

    v EFFICIENCY VI

    v 36-48 WATT OUTPUT POWER

    v OVERCURRENT PROTECTION

    v SHORT CIRCUIT PROTECTION

    v INPUT PROTECTION

    v ROHS COMPLIANT

    Multi-blade Type

    v UL,FCC

    v CB,CE,UKCA

    v SAA,PSE,CCC,KC,BIS,BSMI

    v REACH, ROHS

    TYPICAL MODEL LIST
    I/P VoltageTypical modelOutput VoltageOutput CurrentRipple & noiseEfficiency Level

    90 - 264V

    47 - 63HZ

    ICP48-090-50009V5000mA90mV6 Level IIIIII
    ICP48-120-400012V4000mA90mV6 Level IIIIII
    ICP48-150-300015V3000mA120mV6 Level IIIIII
    ICP48-180-266618V2666mA120mV6 Level IIIIII
    ICP48-240-200024V2000mA150mV6 Level IIIIII
    ICP48-360-133336V1333mA150mV6 Level IIIIII
    INPUT SPECIFICATIONSGENERAL SPECIFICATIONS
    Input Voltage90〜264VACPrimary to Secondary50MΩ MIN
    Input Frequency47〜63HzEfficiencyVI
    Input Current1.2A MaxStandby Power0.30W MAX
    Inrush Current40.0A MaxLeakage Current0.25mA MAX
    OUTPUT SPECIFICATIONSENVIRONMENTAL SPECIFICATIONS
    Output Voltage Range5V-36VOperating Temperature10°C~40°C
    Output Current Range100mA-5000mACoolingConvection
    Output Power Range48.0W MaxTemperature Coefficient0.05%/°C
    Short Circuit ProtectionAutomatic RecoveryHumidity5~95%RH(non-condensing)
    Over-Current ProtectionAutomatic RecoveryStorage Temperature-20°C~+80%°C
    Ripple and Noise100mVp-p maxPHYSICAL SPECIFICATIONS
    Turn On Time20-30mS normalPhysical Specifications97.7mm *45.7mm *32.7mm
    Line Regulation1% maxSAFETIES STANDARD
    Output Regulation±5%Safeties Standard62368 / 60950/ 60335/ 61558/ 60065 /UL1310

    Product Pictures


    About this item
    * 45W Power Delivery 3.0: Deliver a quick charge with up to 45W for virtually all your mobile devices including a wide range of NO more than 45W laptops, tablets, smartphones, mobile devices, and more. PD 3.0 With PPS technology can provide high-speed charging for most mobile phone device
    * Compact size: small but powerful thanks to innovative GaN technology; design includes a foldable plug for travel-friendly portability
    * Safety features: integrated over-voltage, overheating, and short-circuit protection to keep connected devices safe
    About us:
    Q1: Are you a factory or trading company? A1: We are factory with private- owned industrial park and two branch companies in Huizhou and Shenzhen City. Total over 900 workers . Q2: What is your main products? A2: Mainly producing USB home charger, USB Travel Charger, USB car charger and USB cables. Q3: How about the delivery date? A3: In General, lead time will be 7~15 workdays for normal buy quantity. But if bigger order, please check us further. Q4: How about the label and the logo? A4: Customize label and logo is workable. Q5: How about the MOQ? A5: OEM MOQ is 2000pcs. Q6: What about the warranty? A6: All our goods with 12 months after-sales service..
