18w rechargeable aa intelligent battery charger lead acid batter charger for kid toy

FEATURES			SAFETIES APPROVALS		PRODUCTS PICTURE
v EFFICIENCY VI v 12-20 WATT OUTPUT POWER v OVERCURRENT PROTECTION v SHORT CIRCUIT PROTECTION v INPUT PROTECTION v ROHS COMPLIANT			US Type v UL v CB v FCC v ROHS v REACH
TYPICAL MODEL LIST
I/P Voltage	Typical model		Output Voltage	Output Current	Ripple & noise		Efficiency
90 - 264V 47 - 63HZ	SAW20E-050-3000		5V	3000mA	60mV		VI
	SAW20E-060-3000		6V	3000mA	60mV		VI
	SAW20E-090-2000		9V	2000mA	60mV		VI
	SAW20E-120-1500		12V	1500mA	60mV		VI
	SAW20E-180-1000		18V	1000mA	60mV		VI
	SAW20E-240-1333		24V	1333mA	60mV		VI
INPUT SPECIFICATIONS				GENERAL SPECIFICATIONS
Input Voltage		90〜264VAC		Primary to Secondary		50MΩ MIN
Input Frequency		47〜63Hz		Efficiency		VI
Input Current		0.6A Max		Standby Power		0.1W MAX
Inrush Current		40A Max		Leakage Current		0.25mA MAX
OUTPUT SPECIFICATIONS				ENVIRONMENTAL SPECIFICATIONS
Output Voltage Range		5.00V-36.00V		Operating Temperature		10°C~40°C
Output Current Range		100mA-3000mA		Cooling		Convection
Output Power Range		20W Max		Temperature Coefficient		0.05%/°C
Short Circuit Protection		Automatic Recovery		Humidity		5~95%RH(non-condensing)
Over-Current Protection		Automatic Recovery		Storage Temperature		-20°C~+80%°C
Ripple and Noise		100mVp-p max		PHYSICAL SPECIFICATIONS
Turn On Time		20-30mS normal		Physical Specifications		59.3mm *40.3mm *26.3mm
Line Regulation		1% max		SAFETIES STANDARD
Output Regulation		±5%		Safeties Standard		62368 / 60950/ 60335/ 61558/ 60065

Yingyuan is one famous brand on power adapter and battery chargers, which is established in 2006.

it becomes one integrated high-tech enterprise which includes the reseach and develop-ment,production ,

sales and trade on li-ion battery charger, lifepo4 battery charger, nimh battery charger, lead acid battery charger

and power adpater within 3600 watts. Based on our strong R&D team and long-term experience,

We have CE FCC CB GS UL SAA KC PSE etc certifications for our products. and with our ISO9001 to control the factory

and the prouct, we provide warran-ty with 3 years to each customers.

Our mission is to serve your purchase needs with enthusiasm and professionalism, to provide best offer solution to save your

cost, to share profit with premium clients, to create win-win business mode, and boost your business as a result. If you are

looking for supplier with top quality products at competitive prices, Yingyuan is the best option for you forever.

FQA

Q1. What are your main products?
Power Supply: 0-150W with 3V 4.5V 5V 6V 7V 9V 10V 12V 15V 18V 19V 20V 24V 25V 30V 36V 48V 60V Outputs

Battery Chargers within 1500W
Lithium/Lipo battery charger
Lifepo4 battery charger
Lead acid battery charger
Nimh/Nicd battery charger

Q2. What is the warranty of your products?
A: 3 years. we can offer the new ones to replace that defective products under warranty.

Q3: What certifications you have?
A: CE ROHS CB GS FCC UL SAA KC KCC PSE CCC for most of products

Q4. What is the lead time?
A: 2-5 days for samples, 25-30 days for mass order.

Q5. What is the shipping way?
A: samples by air, mass order by air or sea. air shipment always choose Fedex,TNT, UPS, DHL with 4-5 days arrival.

Q6. What is the charging mode for your battery chargers?
CC--CV mode for Lithium ion/Lifepo4 Battery charger
CC--CV--Float mode for lead acid battery
CC--CV--Trickle mode for nimh battery

We are specialized in the design, manufacture of 5W to 120W power supplies, vehicle power adapters, USB chargers, and 100W to 3600W battery chargers. Almost all our products are with safety approvals such as UL, CE, GS, RCM, PSE, KC, KCC, BS, CCC, and so on. Our customers are from all over the world including the United States, Canada, Europe, Japan, Korea, and so on.

Our R& D department has more than 30 professional technicians and engineers. During these years, we have developed hundreds of products and obtained more than 30 patents. Our battery charger and usb charger factory is equipped with a total of 8 automatic production lines. And thanks to modern production and testing devices, our factory stable output can reach 2.4Millions units/ month.

Always attaching great importance to product quality and environmental protection, we are approved by the ISO9001 quality management system and ISO14001 environment management system. Over the years, our factory has won credibility from numerous Chinese and international customers. Our ideas are Integrity, Dedication, Practicability, innovation and to be one of the leaders in this industry. Warmly welcome you to visit us and make win-win cooperation!
