60W 24 Volt Ac Power Adapter Ac Dc Plug Adapter 9v Ac Power Adapter Ul Ce Ukca Doe Vi

About us:

Shenzhen Yingyuan Co., Ltd. is a 16 years national-level innovative high-tech enterprise integrating R&D, production and sales,

focusing on the production of efficient,energy-saving, environmentally friendly and safe products and OEM ODM customized services

and after-sales services to provide customers High-quality products and excellent service are our responsibility. The company was

established in Baoan District, Shenzhen in October 2006. It has more than 800 employees. It has passed ISO9001 and ISO14001 certifications.

FEATURES			SAFETIES APPROVALS		PRODUCTS PICTURE
v AU US UK EU CN JP KR Plugs v EFFICIENCY VI v 48-65 WATT OUTPUT POWER v OVERCURRENT PROTECTION v SHORT CIRCUIT PROTECTION v INPUT PROTECTION v ROHS COMPLIANT			Multi-blade Type v UL,FCC v CB,CE,UKCA v SAA,PSE,CCC,KC,BIS,BSMI v REACH, ROHS
TYPICAL MODEL LIST
I/P Voltage	Typical model		Output Voltage	Output Current	Ripple & noise		Efficiency Level
90 - 264V 47 - 63HZ	ICP65-050-7000		5V	7000mA	90mV		VI 6V IIIIII
	ICP65-090-6000		9V	6000mA	90mV		VI 6V IIIIII
	ICP65-120-5000		12V	5000mA	120mV		VI 6V IIIIII
	ICP65-180-3300		18V	3300mA	120mV		VI 6V IIIIII
	ICP65-240-2500		24V	2500mA	150mV		VI 6V IIIIII
	ICP65-480-1250		48V	1250mA	150mV		VI 6V IIIIII
INPUT SPECIFICATIONS				GENERAL SPECIFICATIONS
Input Voltage		90〜264VAC		Primary to Secondary		50MΩ MIN
Input Frequency		47〜63Hz		Efficiency		VI
Input Current		1.2A Max		Standby Power		0.3W MAX
Inrush Current		40A Max		Leakage Current		0.25mA MAX
OUTPUT SPECIFICATIONS				ENVIRONMENTAL SPECIFICATIONS
Output Voltage Range		5.0V-48V		Operating Temperature		10°C~40°C
Output Current Range		100mA-7000mA		Cooling		Convection
Output Power Range		65.00W Max		Temperature Coefficient		0.05%/°C
Short Circuit Protection		Automatic Recovery		Humidity		5~95%RH(non-condensing)
Over-Current Protection		Automatic Recovery		Storage Temperature		-20°C~+80%°C
Ripple and Noise		100mVp-p max		PHYSICAL SPECIFICATIONS
Turn On Time		20-30mS normal		Physical Specifications		117.1mm *50.1mm *33.1mm
Line Regulation		1% max		SAFETIES STANDARD
Output Regulation		±5%		Safeties Standard		62368 / 60950/ 60335/ 61558/ 60065

AC DC Plug

Certification

FQA:

Q1:Do you have OEM/ODM service? Can I have my own logo on the adapter?
A1:OEM/ODM is available. For logo, we can do laser and Screen print or print your logo on the label.

Q2:How to get a sample?
A2:We offer 1-3 free samples for you to test once all details parameters confirmed,while you just need to pay for the freight.

Q3: How does your factory do related quality control?
A4: Quality is top priority. Firstly, we will control the raw material; secondly, every worker does his job on the production line
to ensure the professional; lastly, all products will be full tested well before packing.

Q4: What is the warranty of your products?
A5: The warranty is 36 months; if the products do not work in the warranty period, please let us know them in detail and show us
the relative picture, we will give after-sale service according to the situation.

Q5:Which payment terms do you offer?
A5:L/C T/T open account transaction, western union & Paypal

We are specialized in the design, manufacture of 5W to 120W power supplies, vehicle power adapters, USB chargers, and 100W to 3600W battery chargers. Almost all our products are with safety approvals such as UL, CE, GS, RCM, PSE, KC, KCC, BS, CCC, and so on. Our customers are from all over the world including the United States, Canada, Europe, Japan, Korea, and so on.

Our R& D department has more than 30 professional technicians and engineers. During these years, we have developed hundreds of products and obtained more than 30 patents. Our battery charger and usb charger factory is equipped with a total of 8 automatic production lines. And thanks to modern production and testing devices, our factory stable output can reach 2.4Millions units/ month.

Always attaching great importance to product quality and environmental protection, we are approved by the ISO9001 quality management system and ISO14001 environment management system. Over the years, our factory has won credibility from numerous Chinese and international customers. Our ideas are Integrity, Dedication, Practicability, innovation and to be one of the leaders in this industry. Warmly welcome you to visit us and make win-win cooperation!
