60W 12v Ac Dc Power Adapter 10 Volt Dc Power Adapter 15v Dc Power Adapter 24 Volt

Advantage:

Professional

15 years’ experience of Power Adapters Production

Yingyuan is a professional factory specializing in R&D and production of power adapters only,which doesn’t supply any other

hot selling electronic products. That is why we can keep advanced skills and stable quality all the time.

Cooperating with Famous Companies
With good products and business reputation,Yingyuan has won the trust of various famous companies
We've established long term partnetship with the companies as Gree , Samsung ,Walmart ETC.

Reliable

· ISO9001 Certification and Assessed Supplier on Alibaba

We have already passed ISO factory inspection and have been an Assessed Supplier on Alibaba.

· AQL Acceptance Standards

The final inspection shipments will be in strict accordance with the AQL acceptance standards.The power adapter shall be

burnt for 4 hours under normal input and 80% rated load at 40°C +/- 5 °C

- Shipping methods

Express/Air Transportation: DHL,UPS,FEDEX,EMS,TNT,etc.

Sea Transportation: COSCO, CSCL, CNC, DONGNAMA, EMC, NYK, GOLDSTAR, OOCL, SYMS, SINOTARANS, SITC, TMSC, WANHAI,

YML, MAERSK etc.

FEATURES			SAFETIES APPROVALS		PRODUCTS PICTURE
v EFFICIENCY VI v C6, C8, C14 AC Socket v 48-65W WATT OUTPUT POWER v OVERCURRENT PROTECTION v SHORT CIRCUIT PROTECTION v INPUT PROTECTION v REACH, ROHS COMPLIANT			Desktop Type v UL, FCC v CB, CE, UKCA v CCC, KC, PSE v SAA v REACH, ROHS
TYPICAL MODEL LIST
I/P Voltage	Typical model		Output Voltage	Output Current	Ripple & noise		Efficiency
90 - 264V 47 - 63HZ	CGSW60-050-7000		5V	7000mA	90mV		VI 6.0 Level
	CGSW60-090-6000		9V	6000mA	90mV		VI 6.0 Level
	CGSW60-120-5000		12V	5000mA	120mV		VI 6.0 Level
	CGSW60-180-3300		18V	3300mA	120mV		VI 6.0 Level
	CGSW60-240-2500		24V	2500mA	150mV		VI 6.0 Level
	CGSW60-480-1250		48V	1250mA	150mV		VI 6.0 Level
INPUT SPECIFICATIONS				GENERAL SPECIFICATIONS
Input Voltage		90〜264VAC		Primary to Secondary		50MΩ MIN
Input Frequency		47〜63Hz		Efficiency		VI
Input Current		1.2A Max		Standby Power		0.3W MAX
Inrush Current		40A Max		Leakage Current		0.25mA MAX
OUTPUT SPECIFICATIONS				ENVIRONMENTAL SPECIFICATIONS
Output Voltage Range		5.00V-48.00V		Operating Temperature		10°C~40°C
Output Current Range		100mA-7000mA		Cooling		Convection
Output Power Range		65.00W Max		Temperature Coefficient		0.05%/°C
Short Circuit Protection		Automatic Recovery		Humidity		5~95%RH(non-condensing)
Over-Current Protection		Automatic Recovery		Storage Temperature		-20°C~+80%°C
Ripple and Noise		100mVp-p max		PHYSICAL SPECIFICATIONS
Turn On Time		20-30mS normal		Physical Specifications		117.3mm *50.3mm *33.3mm
Line Regulation		1% max		SAFETIES STANDARD
Output Regulation		±5%		Safeties Standard		62368 / 60950/ 60335/ 61558/ 60065 / UL1310

Certification

WHY US
1. What we sell is 100% Genuine Yingyuan Power Supply;
2. Small quantity orders acceptable;
3. We will choose the most suitable shipping way for you and inform you the cost advance, decision will be made by you;
4. We have larger stocks and this support us can make a very prompt shipping;
5. To assure you the maximum comfort and satisfaction, we accept pay via T/T, Paypal, Western Union;
6. Price could be negotiated for more and large quantity;
7. Your enquiry will be quickly responded, we will choose the most suitable products and quote the most competitive price for you.

We are specialized in the design, manufacture of 5W to 120W power supplies, vehicle power adapters, USB chargers, and 100W to 3600W battery chargers. Almost all our products are with safety approvals such as UL, CE, GS, RCM, PSE, KC, KCC, BS, CCC, and so on. Our customers are from all over the world including the United States, Canada, Europe, Japan, Korea, and so on.

Our R& D department has more than 30 professional technicians and engineers. During these years, we have developed hundreds of products and obtained more than 30 patents. Our battery charger and usb charger factory is equipped with a total of 8 automatic production lines. And thanks to modern production and testing devices, our factory stable output can reach 2.4Millions units/ month.

Always attaching great importance to product quality and environmental protection, we are approved by the ISO9001 quality management system and ISO14001 environment management system. Over the years, our factory has won credibility from numerous Chinese and international customers. Our ideas are Integrity, Dedication, Practicability, innovation and to be one of the leaders in this industry. Warmly welcome you to visit us and make win-win cooperation!
